Sound-insulated energy-saving inline fan Lineo 100 Quiet ES up to 300 m³/h airflow

if(!document.getElementById('paypal-smart-payment-script')) { var script = document.createElement("script"); script.type = "module"; script.id = "paypal-smart-payment-script"; script.src = "https://cdn02.plentymarkets.com/wzjm2a03n3t8/plugin/14/paypal/js/smartPaymentScript.min.js"; script.setAttribute("data-client-id", "AfslQana4f4CQjHvRBnUc6vBJg5jgJuZFwM-SbrTiGKUAqB7MrxQv3QWFdQ6U1h7ogMDokT1DNBzRxMw"); script.setAttribute("data-user-id-token", ""); script.setAttribute("data-merchant-id", "XR9BDMR6U9VWW"); script.setAttribute("data-currency", "EUR"); script.setAttribute("data-append-trailing-slash", ""); script.setAttribute("data-locale", "en_GB"); script.setAttribute("sandbox", ""); script.setAttribute("googlePayComponent", 0); script.setAttribute("applePayComponent", 0); script.setAttribute("logToken", "9b426775c8aa14378b88a69154c7d8f9"); document.body.appendChild(script); } else { var script = document.getElementById('paypal-smart-payment-script'); script.src = "https://cdn02.plentymarkets.com/wzjm2a03n3t8/plugin/14/paypal/js/smartPaymentScript.min.js"; script.setAttribute("data-client-id", "AfslQana4f4CQjHvRBnUc6vBJg5jgJuZFwM-SbrTiGKUAqB7MrxQv3QWFdQ6U1h7ogMDokT1DNBzRxMw"); script.setAttribute("data-user-id-token", ""); script.setAttribute("data-merchant-id", "XR9BDMR6U9VWW"); script.setAttribute("data-currency", "EUR"); script.setAttribute("data-append-trailing-slash", ""); script.setAttribute("data-locale", "en_GB"); script.setAttribute("sandbox", ""); script.setAttribute("googlePayComponent", 0); script.setAttribute("applePayComponent", 0); script.setAttribute("logToken", "9b426775c8aa14378b88a69154c7d8f9"); }

if (typeof paypal_plenty_sdk === 'undefined' || typeof renderPayPalButtons !== 'function') { document.addEventListener('payPalScriptInitialized', () => { renderPayPalButtons('67612cb33d326', 'paypal', 'buynow', 'rect', 'gold'); }); } else { renderPayPalButtons('67612cb33d326', 'paypal', 'buynow', 'rect', 'gold'); }

Dimensions and technical details

220-240 V ~ 50/60 Hz
0-10 V interface
Housing colour: black
Housing material: polypropylene
Nominal size: 100 mm
Speed levels: 1
Wattage: 23 W
Current consumption: 0.26 A
Revolutions per minute: 2510
Airflow rate: 300 m³/h
Sound pressure level Lp-3m: 27.4 dB(A)
Total pressure Pmax: 243.2 Pa
Max. temperature of transported air: +60°C
Protection class: IP45
Insulation class: II
Weight: 3.6 kg
Thermal overload protection
Includes mounting bracket
Optional speed controller sold separately
Mounting position: any position
Fan unit can be removed quickly for cleaning and maintenance
Classification of fire E-d2 according to European Standard EN 13501-1

Dimensions in mm	A	B	C	Ø D	E	F	G	H	L	Ø M	N
Lineo 100 Quiet ES	210	294.5	639	97	130	235	135	120	67.5	5.5	320
